智能无应力加热SURETHERM PRO 3X

分享
微信
新浪微博
QQ
豆瓣网
百度贴吧
复制链接
脸书
X
领英
马上咨询
产品详情

The following yokes are included with SURETHERM PRO 3X: 100 x 100. Additional yoke sizes are listed in our Datasheet. Two magnetic temperature sensors with a length of 1000 mm are included as well.

SURETHERM PRO 3X标配轭铁100X100, 包含两个长度为 1000 mm 的磁性温度传感器。


SPECIFICATIONS参数

Voltage电压400 - 480 - 575 Vac
Frequency频率50 / 60 Hz
Max. current最大电流63 A
Weight重量280 kg / 617 lbs
Operating Area (WxH)工件范围435 x 495 mm
17.13 x 19.49"
Footprint (LxB)覆盖范围1080 x 500 mm
42.52 x 19.69"
Workpiece工件
Min. bore diameter最小内径ø 40 mm / ø 1.57"
Max. outer diameter最大外径ø 1500 mm / ø 59.06"
Max. width最大宽度485 mm / 19.09"
Max. weight最大重量800 kg / 1764 lbs
